Stabilisation of open pit wall movements detected by InSAR using horizontal drains

Technical Paper

This paper details the successful mitigation of slope instability at the M15 west slope of the Main Pit at First Quantum Minerals' Kansanshi copper mine in Zambia.



  • SkyGeo's InSAR monitoring service used high-resolution TerraSAR-X imagery to identify a circular subsidence pattern on the M15 west slope, suggesting a complex failure mechanism.

  • The intervention, consisting of depressurisation drilling and horizontal drains starting in November 2022, successfully reduced the slope's displacement rate from -101 mm/year to -53.4 mm/year.

  • InSAR provided continuous, long-term pre-warning of movement that reactivated during the wet season, enabling Kansanshi Mine to plan crest unloading to ensure stability.

  • Timely InSAR intervention allowed for the safe and continued operation of trolley lines and successfully avoided other costs associated with a slope failure, such as increased tramming distance.

Frequently Asked Questions

  • The case study focuses on detecting and managing open pit wall movement, where slope instability can create safety and operational risk. InSAR-based monitoring provided early warning that supported mitigation planning and ongoing operations.

  • Early detection enabled timely intervention, helping reduce the likelihood of failure and avoid associated operational impacts. The broader lesson is that wide-area time-series monitoring can add useful early context—when interpreted by specialists and integrated with site workflows.
